Products / Waterworks / Metal Seated Gate Valve

Dikkan Figure 17EAC.6-DN40-1500

Bookmark Product
Share Product
IOM Download

Gate Valve With Electric Actuator

Metal Seated Gate Valve

  • Stainless Steel

  • Stainless Steel

Technical Specifications

Standard

DIN 3352 T2

Face fo face

EN 558 Series 15 (DIN 3202 F5)

Flange dimension

DIN Flanges acc. to EN 1092-1/B (DIN 2501)

Flange conntecion

PN25

Options

Hydraulic actuator, Pneumatic actuator

  • Stainless Steel Dikkan gate valves with stainless steel trim and indicator, bolted bonnet,
    raised face flanges according to DIN, equipped with electric multi-turn actuator in order
    to provide for the automation of the valve.

  • Application: Hot and cold water, fresh water, seawater, lubricating oil.
